The Solar Knight® liquid level alarm will notify maintenance personnel in the event of a high liquid condition. The system is complete with visual indicators and dry contacts to connect to a dialer (optional) or building automation system.
Features
- Solar cell provides 24/7 continuous power to high liquid alarm panel
- UL Listed for the United States and Canada
- Includes Narrow Angle Float Switch with 20’ cord
- Indoor/Outdoor NEMA 4X rated enclosure: Heavy duty polycarbonate with stainless steel lockable latches
- Includes 10 Watt multi-crystalline solar panel, 12V, 9.0 Amp Hr. sealed rechargeable battery and solar charger
- Quick installation and low maintenance
- High liquid alarm with test and silence deatures, red beacon alarm light, high 85 decibel audible alarm.
- Dry contact for high liquid condition
- Solar panel mounting hardware
- Easily accessible terminal block
Add Pump Portal® remote pump monitoring to this system! LEARN MORE
Applications
- Sewage and wastewater
- Remote or rural containment
- Flood zones
- Industrial sumps
-
Holding tanks
-
Residential tanks
-
Lift stations
-
Leach line
Custom Options
- 28 = Power On Dry Contact
- 3R = Painted Steel Enclosure
- AF = Alarm Flasher
- C = Additional cord length greater than 20’*
- PX = Pump Portal® Wireless Remote Panel Control and System Monitoring
- S3 = No Sensors Included
- SS4 = Upgraded Enclosure (304 Stainless Steel)
- SS6 = Upgraded Enclosure (316 Stainless Steel)
*Additional cord length greater than 20’: Specify after C. Example: (CP1003-C50) Indicates 50’ cable length for narrow angle float.
