Knight Series® FC-40 Level and Temperature Alarm System
Quote Request
Request is being submitted...
Literature
The FC-40 monitors cisterns or reservoirs that supply water for a building’s fire sprinkler system and water containment tanks. It provides a continuous level and temperature information on the panel and dry contacts that connect to the fire panel monitoring system. The FC-40 is ideal for applications where there is a risk of freezing temperatures. The alarm and monitoring features provided meet fire codes and standards for cisterns and fire sprinkler systems.
| Models: | Voltage: |
| FC-40 | 120VAC, 60Hz. |
| FC-40-A | 208/240VAC, 50/60Hz. |
Add Pump Portal® remote pump monitoring to this system! LEARN MORE
Features
- UL Listed for the United States and Canada
- System indicates in the event of temperature below 40°F, low liquid level or power loss
- Complete panel remote monitoring dry contacts (below 40°F, low level or power loss) that are able to connect to fire panel or building management systems
- Temperature monitoring LCD display with adjustable alarm settings
- Includes stainless steel temperature sensor
- Includes low level float (normally closed) with 20’ SJOW cord and mounting clamp
- Battery backup in the event of power loss
- Indoor/Outdoor NEMA 4X rated enclosure: Heavy duty polycarbonate with stainless steel lockable latches
- System has adjustable temperature set points
Applications
- Cisterns/tanks
- Fire sprinkler systems
- Applications that require a level and temperature monitoring
- Above and below ground containment tanks
Options
- C = Additional cord length greater than 20’*
- PC = 10' power cord
- PX = Pump Portal® Wireless Remote Communication
*Additional cord length greater than 20’: Specify after C. Example: (FC-40-C50) Indicates 50’ cable length for low level narrow angle float (normally closed) and temperature sensor.
